Soda/Sparkling Water Filling Machine

Product Description

1. Product introduction
The Jndwater Soda/Sparkling Water Filling Machine adopts isobaric filling technology and is specially designed for the production of carbonated beverages. Achieve filling of carbonated beverages, soda water, beer and other carbonated beverages of all specifications from 200 to 2000ml

2. Carbonated Drink Filling Machine Product features
Positive pressure filling technology: ±0.3% volume filling accuracy, support 0.1ml level fine-tuning
Intelligent gas-liquid separation: CO₂ content control accuracy ±0.1g/L, bubble control technology
High-speed processing capability: single-head efficiency reaches 1500-2500 bottles/hour (330ml bottle)
Modular design: support 18-320mm bottle diameter, 100-450mm bottle height fast changeover

3. Product functions
Intelligent bottle sorting system Servo bottle separation technology, empty bottle positioning accuracy ±0.1mm
Dynamic filling system Servo-driven quantitative pump, support stable delivery of gas-containing liquid
Pressure compensation technology Three-stage decompression system, filling pressure control accuracy ±0.01MPa
Nitrogen replacement system Residual oxygen content in the bottle <1%, CO₂ recovery rate ≥98%
Intelligent capping system Electromagnetic induction torque control, qualified rate ≥99.99%

4. Carbonated Beverage Filling Machine Technical specifications

5. How does the Carbontated Bottling Machine work?
Pretreatment and replacement: Empty bottles enter the bottle washing area through the conveyor chain, and impurities in the bottle are washed by CO₂ or sterile water to establish an isobaric environment.
Precision filling: Carbonated beverages balance the pressure inside and outside the tank, and the liquid is injected along the bottle wall to reduce foam
Sealing and quality inspection: The foaming device removes residual gas before sealing, the magnetic constant torque capping machine ensures sealing, and the sealing pressure is adjustable

6. Applications
Carbonated beverage production enterprises
Beer brewing enterprises
High-end carbonated beverage customized factory (supporting nitrogen + carbon dioxide mixing process)

7.FAQs
Q:What types of beverages are suitable for soft drink filling machines?
A:Carbontated Bottling Machine are suitable for filling various soft drinks such as carbonated drinks, juices, tea drinks, sports drinks, bottled water, etc., especially for filling carbonated drinks.
