Robot Palletizer | Automatic Carton, Bag and Barrel Stacking | JNDTECH
Articulated robot palletizer from JNDTECH for cartons, bags, barrels and special-shaped packaging. Maximum load 30 to 1000 kg, arm span 1200 to 3200 mm, repeat positioning accuracy ±0.04 mm, 1150 to 2100 boxes per hour. Palletizing patterns are stored in the controller and switched from the touch sc
Send InquiryProduct Description
Robot Palletizer for Bottling and Packing Lines
An articulated robot palletizer lifts cartons, bags and barrels off the end of a filling line and stacks them onto pallets without an operator. The arm, gripper and pallet conveyor run from one controller, so a new carton size is set on the touch screen instead of by moving guides.
The JNDTECH robot palletizer carries a maximum load of 30 to 1000 kg depending on the model, with an arm span of 1200 to 3200 mm. That range covers a line end stacking 20 kg cartons of bottled water and a heavy cell moving 200 L drums. Payload, arm span and gripper type are confirmed against your carton and pallet dimensions before the machine is built.
How the Robot Palletizer Works
Five steps repeat for every layer.
- Orientation. Cartons arrive from the carton packing machine on a conveyor. A guide rail squares each one to the pick position, so the gripper always meets the same face.
- Vision scan. A 3D camera or laser sensor measures the carton size and position, then the controller plans the shortest safe path to the pallet.
- Grip. Vacuum suction cups, a clamp gripper or a fork gripper takes the load. The choice follows the packaging: suction for trays, clamps for cases, forks for bags and drums.
- Layer build. The servo system places each carton in the programmed pattern. Repeat positioning accuracy is ±0.04 mm on models fitted with the high precision servo package.
- Pallet exchange. When the pattern finishes, the full pallet moves out on the pallet conveyor and an empty one is indexed in, so the line keeps running.
Speed depends on the pattern and the load, and runs from 1150 to 2100 boxes per hour. Stacking error is held below ±1 mm.
Robot Palletizer Specifications
| Item | Data |
|---|---|
| Maximum load | 30 - 1000 kg (customizable) |
| Arm span | 1200 - 3200 mm |
| Repeat positioning accuracy | ±0.04 mm (models with the high precision servo package) |
| Processing speed | 1150 - 2100 boxes/hour |
| Packaging types | Cartons, bags, barrels, special-shaped packaging |
| Safety devices | Collision detection, overload protection |
| Palletizing pattern | Stored in the controller, switchable from the touch screen |
Power rating, air consumption and footprint follow the arm you select, so they are confirmed on the quotation.
Robot Palletizer or Gantry Palletizer
JNDTECH builds both. The decision comes down to your layout and how many line ends one machine has to serve.
| Item | Robot palletizer | Gantry palletizer |
|---|---|---|
| Structure | Articulated arm on a floor base | Overhead gantry frame |
| Speed | 1150 - 2100 boxes/hour | 10 - 22 bags/minute |
| Handles | Cartons, bags, barrels, special-shaped packaging | Cartons, bags, bottles |
| Footprint | Small, floor mounted | 9120 x 6150 x 3500 mm |
| Rated power | Set by the selected arm | 10 kW |
| Best fit | Several line ends, frequent product or pattern changes | One high volume line, one fixed carton size |
The two speed figures use different units, so read them as separate baselines rather than a direct comparison. For one high speed line running a single carton size, the gantry frame is simpler. When one arm reaches two filling lines, or the format changes between shifts, the robot palletizer wins on changeover time. Full gantry data is on the gantry palletizer page.
Carton, Bag and Barrel Palletizing in Beverage Plants
Most JNDTECH robot palletizers ship into three kinds of plant.
- Bottling lines. Water, juice and carbonated drink lines end at the carton packing machine, and the arm stacks trays and cases at line speed.
- Bags and drums. Mineral water plants palletizing 10 kg and 25 kg bags, and chemical plants stacking 200 L drums, use the higher load arms with fork grippers.
- Mixed format warehouses. Plants where the carton changes between shifts, so the pattern is recalled from the controller instead of re-rigging the machine.
The gripper decides whether a robot palletizer suits your product, so it is chosen before the arm. If you are still comparing machine types, our guide on how to choose a palletizing robot covers the layout questions in detail.
Why Choose JNDTECH
- Since 2008, with machines running in more than 125 countries and 450 factories.
- Supplied as part of a turnkey line, so the arm, the conveyor and the carton packing machine are matched before delivery.
- Pattern programming, gripper selection and operator training handled by our engineers on site.
- 1 year warranty and a 24 hour response line.
- ISO 9001, CE and patented designs.
Frequently Asked Questions
How much floor space does a robot palletizer need? The arm itself is compact and floor mounted, while most of the space claim comes from the pallet conveyor and the safety guard around the working envelope. Send your layout drawing and we will mark the footprint on it.
Can one robot palletizer serve two production lines? Where two line ends sit close together, one arm can be programmed to serve both. Reach is 1200 to 3200 mm by model, so send the distance between the line ends and we will confirm which arm covers it.
What maintenance does it need? Clean the sensors and guide rails daily, check the lubrication of the servo motors and reducers weekly, and update the control program quarterly.
Can it stack onto different pallet sizes? Yes. Pallet size and stacking pattern are set in the controller, and the pallet conveyor is adjusted to match. Tell us the pallet sizes you run and the patterns are loaded before shipping.
Request a Quotation
Send the carton or bag size, the load weight, the pallet size and the speed you need. We will confirm the arm span, the gripper type and the price. Tell us which machine feeds the palletizer and whether the line runs one product or several.
Contact JNDTECH for a quotation, or send the details by WhatsApp and we will reply within 24 hours.
